HZS60/90/120/180 Stationary Concrete Batching Plant

Theoretical Productivity：	60-180m3/h
Type	Belt Conveyor Type
Mixer：	JS1000/JS1500/JS2000/JS3000
Aggregate Batching Machine：	PLD1600/PLD2400/PLD3200

E-mail: info@hf-industry.cn

Tel/WhatsApp: +8613663816343

HZS60/90/120/180 Stationary Concrete Batching Plant

Main Specifications

Model	Aggregates are conveyed into concrete mixer by belt conveyor
	HZS60	HZS90	HZS120	HZS180
Max. Production Capacity (m3/h)	60	90	120	180
Model of Concrete Mixer	JS1000	JS1500	JS2000	JS3000
Max. Aggregate Size(mm)	60/80	60/80	60/80	60/80
Accuracy of Aggregate Weighing (%)	± 2	± 2	± 2	± 2
Accuracy of Cement Weighing (%)	± 1	± 1	± 1	± 1
Accuracy of Water Weighing (%)	± 1	± 1	± 1	± 1
Accuracy of Additive Weighing (%)	± 1	± 1	± 1	± 1
Total Power (kw)	78	112	150	198
Total Weight (kg)	38000	40000	60000	85000

Product Description

Advantages:

1. Quick installation

Steel girder type or fixed type can be selected. It only takes a few hours for the main mixing system of steel girder type mixing station to be unloaded and installed. Together with the control room, batching station and other supporting facilities of the installation of only two to four days can be ready for production.

2. Small area

Uses the method of hoisting and lifting hopper to feed. The hopper and track are specially designed to load and dump aggregate efficiently, greatly reducing the occupied area of the site.

3. Less investment and simple maintenance

Requires less investment, occupies less space, uses less equipment, maintains easily, and operates safely and conveniently.

4. Reasonable design

Mixing platform, measuring platform and lifting system platform fully guarantee the requirements of inspection and maintenance. Sufficient daily working space can be provided when outer protective layer is needed.
